ALLDAQ ADQ-SCU 2.1-BB-LC / Low-Cost Baseboard für Signal Condition Unit (SCU)

Baseboard for Signal Condition Unit (SCU) for connection to ADQ-344.

AI part

• 32 analogue inputs
• AC/DC coupling
• Digital filter stage
• Adjustable attenuation/amplification
• Monitoring output for headphone connection
• 4 digital trigger inputs

AO part

• 4/8 analogue outputs
• Single-ended/differential switching
• Mute switching (mute)
• 4 digital triggering levels

Other features

• Temperature monitoring of the baseboard with threshold value setting and opto-decoupled alarm output
• 3 slots for customised plug-in modules
• PWM output (opto-decoupled)
• Input for ignition signal "terminal 15" (opto-decoupled)
• 8 isolated digital inputs
• 8 isolated digital outputs
• Overall control via I²C bus
• Supplies can be switched via relay (4 x +5V/4A; 4 x +12V/4A)
• Supply via PC power supply unit (+5V, +12V)
