ALLNET ALL4420 / Combi sensor humidity/temp. in housing
Los precios no incluyen IVA ni gastos de transporte
Disponibilidad inmediata, Plazo de entrega aprox. 1-3 días laborables
- Stock: 0
- Nº de artículo 157801
- Fabricantes: ALLNET
- Número de artículo del fabricante: ALL4420
- Código EAN: 4038816157805
- Peso: 0.164kg
- Garantía: 24 Meses
- ¿Preguntas sobre este artículo?
Downloads
Ficha ténica DE
Ficha técnica EN
Ficha técnica ES
Ficha técnica FR
EU RoHS und REACH Erklärung
Highlights:
- new flat desktop / wall mount case made of aluminium
- I2C bus for multiplexing use
- measuring range -40...+125 °C, 0...100 %RH
- resolution temperature 0,01 °C, resolution humidity: 0.01 %
- Measuring accuracy Temp in whole range approx. +/- 0.6° (Typical: -20 + 90° = +/- = 0.2°)
- Measuring accuracy humidity in the whole range approx. +/- 3% (Typical: 0~80% +/- 1,5%)
- ONLY COMPATIBLE WITH ALL34xx/350x/4500/5000
- Angle brackets for wall mounting
Measure, control and regulate automatically and independently
ALLNET has been pursuing the concept of intelligent control of building technology processes via network and Internet for years. Intelligent building technology not only offers more comfort, but also actively promotes the saving of energy costs.
Centrally controlled and accessible via network / Internet, ALLNET building automation products enable intelligent building technology independent of time and location.
Technical Details:
Humidity Sensor Specification
|
Parameter |
Condition |
Value |
Units |
|
Sensor Humidity Accuracy tolerance1 |
Typ. |
±1.5 |
%RH |
|
Max. |
 |
- |
|
|
Repeatability2 |
Low, typ. |
0.21 |
%RH |
|
Medium, typ. |
0.15 |
%RH |
|
|
High, typ. |
0.08 |
%RH |
|
|
Resolution |
Typ. |
0.01 |
%RH |
|
Hysteresis |
at 25°C |
±0.8 |
%RH |
|
Specified range3 |
extended4 |
0 to 100 |
%RH |
|
Response time5 |
t63% |
86 |
s |
|
Long-term drift |
Typ.7 |
<0.25 |
%RH/yr |
Temperature Sensor Specification
|
Parameter |
Condition |
Value |
Units |
|
ALL3020 Accuracy tolerance1 |
typ., 20°C to 60°C |
±0.1 |
°C |
|
Max. |
 |
- |
|
|
Repeatability2 |
Low, typ. |
0.15 |
°C |
|
Medium, typ. |
0.08 |
°C |
|
|
High, typ. |
0.04 |
°C |
|
|
Resolution |
Typ. |
0.01 |
°C |
|
Specified Range |
- |
-40 to 125 |
°C |
|
Response time 8 |
t63% |
>2 |
s |
|
Long Term Drift |
max |
<0.03 |
°C/yr |
Produktmerkmale:
| Bauform: | Metallgehäuse |
| Einsatzorte MSR: | indoor |
| Kompatibilität Zentrale: | ALL3418, ALL3419, ALL3420, ALL3500, ALL3500PoE, ALL3692, ALL3696, ALL4176, ALL4500, ALL5000, ALL5000v2, ALL5100, PoE Signallampe |
| Sensorart: | Luftfeuchte, Temperatur |
