ALLNET MSR IO central switching socket ALL3075v4 incl. WLAN & current measurement for IP building automation
Los precios no incluyen IVA ni gastos de transporte
Disponibilidad inmediata, Plazo de entrega aprox. 1-3 días laborables
- Stock: 0
- Nº de artículo 104248
- Fabricantes: ALLNET
- Número de artículo del fabricante: ALL3075v4
- Código EAN: 4038816104243
- Peso: 0.45kg
- Garantía: 24 Meses
- ¿Preguntas sobre este artículo?
Downloads





A destacar:
- Permite la conmutación del dispositivo conectado (hasta 16A) vía el servidor web integrado
- Registro/visualización del consumo/corriente alterne/frecuencia "Hz"/factor de potencia
- Conexión a red 10/100 Mbit RJ45 & Wireless LAN
- Conector Schutzkontakt
- Para voltaje de 200-250V
- Posibilidad de conmutación según tiempo, consumo, programado o manual
A través del ALL3075v4 enchufe de red se pueden comutar dispositivos eléctricos de forma manual, por tiempo y/o programas definidos. El ALL3075v4 actua aquí como conector intermedio entre la toma de corriente y el dispositivo electrónico. Se puede integrar via LAN o WLAN a una red local y recibe una determinada dirección IP. La configuración y el manejo son independientes a una plataforma o sistema operativo desde cualquier servidor web en un PC, MAC, tablet o smartphone. No es necesario algun Software adicional.
El ALL3075v4 registra y almacena el consumo energético del dispositivo conectado. Los procesos de conmutación se pueden programar manualmente, por tiempo o según consumo. Se pueden conmutar varios ALL3075v4 indepnedientemente. Además se pueden integrar con otras solución de automatización de ALLNET.
Ejemplos de aplicación:
- Control especifico y reinicio de PC y servidores de forma remota
- Reinicio de Router de forma remota incluyendo encendido automático (tiempo muerto programable)
- Eliminiación temporizada de consumo innecesario, debido a dispositivo en Standby
- Registro de consumo & conmutación individual de dispositivos dentro del hogar o en la oficina
- Escenarios de conmutación complejos en combinación con otros productos de ALLNET
- Productos de automatización de edificios, incluyendo la influencia de la temperatura, humedad, etc.
- y muchas más aplicaciones..
Características técnicas:
Red: |
10BaseT 100BaseTX |
Conexión de red: |
RJ45 |
Estándares soportados: |
IEEE 802.3, IEEE 802.3u |
Protocolos: |
HTTP/HTTPS TCP/IP |
Gestión/control: |
vía navegador web |
Sistemas operativos: |
Compatible con todos los sistemas operativos |
Rango de voltaje: |
200 - 250V |
Corriente de conmutación: |
Máx. 16 Amperios |
Carcasa: |
Carcasa de plástico con conector Schutzkontakt |
Datos ambientales: |
Temperatura de funcionamiento: 0~40°C |
Dimensiones |
125 x 68 x 40 (60) mm (Alto x Ancho x Hondo) |
Peso: |
200gr (sólo Adaptador) |
Certificación |
CE |
