Ubiquiti Wireless AP WIFI7 • BE20780 • 4x4 • Indoor • 10 GbE • UniFi • E7

Vista preliminar: Ubiquiti Wireless AP WIFI7 • BE20780 • 4x4 • Indoor • 10 GbE • UniFi • E7

Imágenes de artículos similares, pueden diferir de la descripción del producto!

Los precios no incluyen IVA ni gastos de transporte

Disponibilidad inmediata, Plazo de entrega aprox. 1-3 días laborables

EU RoHS und REACH Erklärung

Stock: 0
Nº de artículo 237425
Fabricantes: Ubiquiti_Enterprise
Número de artículo del fabricante: E7
Código EAN: 810084694664
Peso: 3kg
Garantía: 12 Meses
¿Preguntas sobre este artículo?

This item can only be sold if a project has been registered beforehand. Project registration at...más

Cerrar menú

Información del producto "Ubiquiti Wireless AP WIFI7 • BE20780 • 4x4 • Indoor • 10 GbE • UniFi • E7"

This item can only be sold if a project has been registered beforehand. Project registration at ubiquiti@allnet.de

Highlights:

WiFi 7 with 6 GHz support
10 round-the-clock streams
Real-time spectral analysis for improved channel selection
Dedicated spectrum analyser radio
6 GHz power with long range and AFC*
185 m² (2,000 ft²) coverage
Over 1,000 connected devices
(1) 10 GbE RJ45 port and (1) GbE RJ45 port for power and data redundancy
Depot-compatible mounting system**
Power supply via PoE++

Enterprise-class indoor access point with 10-stream Wi-Fi 7 performance, a 10 GbE uplink and a redundant GbE port for high availability.

Technical data

Mechanical
Dimensions	250 x 250 x 43.5 mm (9.8 x 9.8 x 1.7 inches)
Weight	1.8 kg
Handle material	UV-stabilised polycarbonate, aluminium alloy
Mounting material	Stainless steel (SUS304), galvanised steel (SGCC)
Hardware
Network interface	(1) 10 GbE RJ45 port (1) 1 GbE RJ45 port
Management interface	Ethernet
Power method	PoE++
Power supply	UniFi PoE switch
Supported voltage range	42.5–57 V direct current
Max. Power consumption	43W
Max. Transmission power 2.4 GHz 5 GHz 6 GHz	23 dBm 30 dBm 24 dBm / 30* dBm *With 6 GHz extended range mode. Only available in the FCC/IC region.
MIMO 2.4 GHz 5 GHz 6 GHz	2 x 2 (DL/UL MU-MIMO) 4 x 4 (DL/UL MU-MIMO) 4 x 4 (DL/UL MU-MIMO)
Max. Data rate 2.4 GHz 5 GHz 6 GHz	688 Mbit/s (BW40) 8.6 Gbit/s (BW240) 11.5 Gbit/s (BW320)
Antenna gain 2.4 GHz 5 GHz 6 GHz	5 dBi 6 dBi 6 dBi
Antenna	Internal with omni pattern
LEDs	R/G/B
Button	Factory reset
Mounting	Wall/ceiling (included)
Operating ambient temperature	-30 to 50 °C (-22 to 122 °F)
Humidity during operation	5 to 95 % non-condensing
Certifications	CE, FCC, IC
Software
WLAN standards	802.11a/b/g/n/ac/ax/be (WLAN 6, WLAN 7)
Wireless security	WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK)
BSSID	8 per radio
VLAN	802.1Q
Advanced QoS	Rate limitation per user
Isolation of guest traffic	Supported
Concurrent clients	&over 1,000
Ubiquiti-specific functions	Dedicated spectrum analyser radio
Supported data rates
802.11a	6, 9, 12, 18, 24, 36, 48, 54 Mbit/s
802.11b	1, 2, 5.5, 11 Mbit/s
802.11g	6, 9, 12, 18, 24, 36, 48, 54 Mbit/s
802.11n	6.5 Mbit/s to 600 Mbit/s (MCS0 – MCS31, HT 20/40)
802.11ac	6.5 Mbit/s to 3.4 Gbit/s (MCS0 – MCS9 NSS1/2/3/4, VHT 20/40/80/160)
802.11ax (WLAN 6)	7.3 Mbit/s to 4.8 Gbit/s (MCS0 – MCS11 NSS1/2/3/4, HE 20/40/80/160)
802.11be (WLAN 7)	7.3 Mbit/s to 11.5 Gbit/s (MCS0 – MCS13 NSS1/2/3/4, EHT 20/40/80/160/240/320)
Application requirements
UniFi network	Version 8.6.9 and higher
UniFi OS	Version 4.0.20 and higher
